(Deep Sea DSE) SWITCHING REGULATOR 6.5/32VDC to 5VDC 500mA
Form
The DC/DC converter provides a stable 5 V DC regulated output from a wide input voltage range.
It is designed for direct wiring installation without a PCB, suitable for compact and efficient power conversion.
- converter type: switching regulator, non-isolated
- output type: single output, wired SIP3 package
- input voltage range: 6.5 – 32 V DC
- nominal output voltage: 5.0 V DC
- maximum output current: 0.5 A
- output power: 2.5 W
Per piece.
Fit
Input and output wires (AWG 22) pre-attached:
- +Vin (red), GND (black), +Vout (brown)
The converter includes internal diode protection against reverse current,continuous short-circuit protection with automatic recovery
Suitable for LED lighting, battery-powered systems, fans, and embedded devices
Function
A DC/DC switching regulator converts a variable input voltage into a stable 5 V DC output.
It provides full protection against short circuits, reverse current, and over-temperature.
