NETWORK SWITCH, 8 ports 1000mbps

STD ADAPNETWS08

Valid Article

Former Code(s): ADAPSWITN8 ADAPSWITN1- ADAPSWITN08 ADAPZNL0069 +
OC subscriptions: included in supply or field order tools (e.g. UniField)
SC subscriptions: included in supply or field tools
OC validations: approved for procurement and use by an OC for international or local orders specifying context and activity in Medical Standard Lists (MSL)

    This combination does not exist.

    Add article to list



    Add Kit To Wishlist



    Definition

    Device which allows to increase the number of connections within a computer network through ports called Ethernet or RJ45.

    Specifications

    Unmanaged switches work right out of the box, with no software to instal and nothing to configure. Each switch port independently sets itself for the optimal speed and determines whether to run in half- or full-duplex mode automatically. They are also designed to immediately accommodate all of the devices in your network.

    Open article, with the following specifications:

    • number of ports: minimum 8
    • speed (bandwidth): minimum 1Gbps
    • cooling system: passive (no fan)
    • power supply: 110 - 220
    • automatic cable detection, so you don't have to worry about using the wrong cable type
    • compatibility with network devices from other vendors

    APU delivers: JH329A HPE ProCurve 1420-8G

    Instructions for use

    Make sure the network switch is always powered (UPS) and protected from voltage fluctuations and surge.

    Air must be able to flow freely around the switch, especially in hot countries.

    It is possible to connect several switches together but it is important to keep their number as low as possible.

    Should be out of reach of users.

    Should be preferably grounded.

    Advice for local purchase

    If absolutely necessary, stick to the MSF requirements as much as possible.

    MSF requirements

    • Ports: to be oversized (24 or/and 48 advised)
    • As quiet as possible (fanless)
    • Internal power supply
    • Non administrable and "plug and play"
    • Rackable
    • At least a 5 year warranty
