KIT, STANDARD MODIFICATION, for HZJ79 pick-up, series 2

Definition

Equipment for preparing a Toyota HZJ pick-up series 2 for heavy duty use.

Indications

The complete list of modifications is detailed in the assembly instructions (available from your technical department).

The modifications can be done in the field or in Europe before sending the vehicle.

Instructions for use

These modifications are standard for all HZJ Toyotas used by MSF.

When the kit is ordered separately from the vehicle, it can be set up locally by a mechanic with a basic tool kit at his disposal. In this case, the kit is sent with assembly instructions.

Some restricted information has been hidden. Sign in to see this information
[CWATBANDM13] HOSE CLAMP, galvanized, Ø12-13mm, type mini CWATBANDM13 STD HOSE CLAMP, galvanized, Ø12-13mm, type mini 4 mandatory
[CWATCGRET38QY] REDUCER COUPLING threaded, galvanized, ⅜"-¼", MxF CWATCGRET38QY STD REDUCER COUPLING threaded, galvanized, ⅜"-¼", MxF 2 mandatory
[PHDWNIPPSQIM] GREASE NIPPLE straight, male thread, ¼" PHDWNIPPSQIM STD GREASE NIPPLE straight, male thread, ¼" 2 mandatory
[PPACBOXC0M801] CARDBOARD BOX, 1830x750x450mm PPACBOXC0M801 STD CARDBOARD BOX, 1830x750x450mm 1 mandatory
[PPACPADLKB5] PADLOCK, brass, 50mm + key PPACPADLKB5 STD PADLOCK, brass, 50mm + key 1 mandatory
[TVEAHOSEF7M] FUEL HOSE, internal Ø 7mm, 1m TVEAHOSEF7M NST FUEL HOSE, internal Ø 7mm, 1m 3 mandatory
[TVEAJACKH12] JACK Hi-Lift, 125cm, SWL 2113 kg TVEAJACKH12 STD JACK Hi-Lift, 125cm, SWL 2113 kg 1 mandatory
[TVEASCRER2-] RADIATOR PROTECTION net, for HZJ7# Mk2 TVEASCRER2- STD RADIATOR PROTECTION net, for HZJ7# Mk2 1 mandatory
[TVEASCRERVT] (radiator protection net) TIGHTENER for fixing TVEASCRERVT STD (radiator protection net) TIGHTENER for fixing 5 mandatory
[TVECCOUNH12] HOUR COUNTER, 12/24V, digital, for Toyota HZJ TVECCOUNH12 STD HOUR COUNTER, 12/24V, digital, for Toyota HZJ 1 mandatory
[TVEMBATTR3-] RUBBERS SET, for battery carrier, 3 pieces TVEMBATTR3- STD RUBBERS SET, for battery carrier, 3 pieces 1 mandatory
[TVEMBATTRL7] (HZJ78/79) REINFORCEMENT battery, lower part TVEMBATTRL7 STD (HZJ78/79) REINFORCEMENT battery, lower part 1 mandatory
[TVEMBATTRU2] (HZJ7# Mk2) REINFORCED UPPER BATTERY BRACKET TVEMBATTRU2 STD (HZJ7# Mk2) REINFORCED UPPER BATTERY BRACKET 1 mandatory
[TVEMBUMPBF2] (HZJ78/79 Mk2) BULL BAR, FR TVEMBUMPBF2 STD (HZJ78/79 Mk2) BULL BAR, FR 1 mandatory
[TVEMBUMPF5-] (HZJ# Mk2 front fender MSF) RUBBER BUMPER TVEMBUMPF5- STD (HZJ# Mk2 front fender MSF) RUBBER BUMPER 2 mandatory
[TVEMBUMPFC2] (HZJ78/79 Mk2) BUMPER central part, FR TVEMBUMPFC2 STD (HZJ78/79 Mk2) BUMPER central part, FR 1 mandatory
[TVEMBUMPFL2] (HZJ78/79 Mk2) BUMPER left part, FR TVEMBUMPFL2 STD (HZJ78/79 Mk2) BUMPER left part, FR 1 mandatory
[TVEMBUMPFR2] (HZJ78/79 Mk2) BUMPER right part, FR TVEMBUMPFR2 STD (HZJ78/79 Mk2) BUMPER right part, FR 1 mandatory
[TVEMBUMPFT2] (HZJ78/79 serie 2) TOWING RING, FR TVEMBUMPFT2 STD (HZJ78/79 serie 2) TOWING RING, FR 2 mandatory
[TVEMBUMPLB2] (HZJ78/79 Mk2) BUMPER SUPPORT left side, FR TVEMBUMPLB2 STD (HZJ78/79 Mk2) BUMPER SUPPORT left side, FR 1 mandatory
[TVEMBUMPPF2] (HZJ78/79 Mk2) CORNER PLATE, FR bumper support TVEMBUMPPF2 STD (HZJ78/79 Mk2) CORNER PLATE, FR bumper support 2 mandatory
[TVEMBUMPRB2] (HZJ78/79 Mk2) BUMPER SUPPORT right side, FR TVEMBUMPRB2 STD (HZJ78/79 Mk2) BUMPER SUPPORT right side, FR 1 mandatory
[TVEMBUMPRJ9] (HZJ79) BUMPER, RR + high-lift jack support, 2 pcs TVEMBUMPRJ9 STD (HZJ79) BUMPER, RR + high-lift jack support, 2 pcs 1 mandatory
[TVEMFIXAFS-] FIXING POINT STRAPS + counter plate TVEMFIXAFS- STD FIXING POINT STRAPS + counter plate 2 mandatory
[TVEMFIXAJP9] HIGH JACK SUPPORT, for pickup TVEMFIXAJP9 NST HIGH JACK SUPPORT, for pickup 1 mandatory
[TVEMFIXANES] NUTS & BOLTS SET, for kit MSF stand. modif., for HZJ78 s. 2 TVEMFIXANES STD NUTS & BOLTS SET, for kit MSF stand. modif., for HZJ78 s. 2 1 mandatory
[TVEMWHEEBF7] (HZJ78/79 series 2) INFERIOR FRONT SLEEPER TVEMWHEEBF7 STD (HZJ78/79 series 2) INFERIOR FRONT SLEEPER 1 mandatory
[TVEMWHEESH7] (HZJ78/79) HANDLE spare wheel fixing TVEMWHEESH7 STD (HZJ78/79) HANDLE spare wheel fixing 1 mandatory
[TVEMWHEESP7] (HZJ78/79) RETAINING PLATE spare wheel TVEMWHEESP7 STD (HZJ78/79) RETAINING PLATE spare wheel 1 mandatory
[TVEMFIXAF9D] (HZ79 double cabin) ROLL-BAR FRAMEWORK, the pair TVEMFIXAF9D NST (HZ79 double cabin) ROLL-BAR FRAMEWORK, the pair 1 optional
[TVEMFIXAF9S] (HZ79 single cabin) ROLL-BAR FRAMEWORK, the pair TVEMFIXAF9S NST (HZ79 single cabin) ROLL-BAR FRAMEWORK, the pair 1 optional
