COLD BOX (B Medical RCW)

Definition

Isothermal container which is lined with frozen ice packs to keep large quantities of temperature-sensitive products between +2 ºC and +8 ºC for several days.

Used for mobile vaccination sessions and transportation between stores.

Specifications

  • External surface: polyethylene
  • Insulation material: polyurethane

B Medical RCW25/CF:

  • Storage capacity: 20.7 litres (= 7.000 doses of measles vaccine)
  • Cold life without opening at +43 ºC: 129 hrs
  • Supplied with 24 ice packs of 0.6 litres
  • External dimensions: 71 x 55 x 50 cm
  • Weight when empty: 17 kg

B Medical RCW12/CF:

  • Storage capacity: 8.5 litres
  • Cold life without opening at +43 ºC: 114 hrs
  • Supplied with 14 ice packs of 0.6 litres
  • External dimensions: 50 x 47 x 55 cm
  • Weight when empty: 11.7 kg
Some restricted information has been hidden. Sign in to see this information

Instructions for use

Can also be used for storage at the local level when there is no refrigerator, provided that the icepacks are renewed regularly.

Keep cold-boxes in the shade and avoid using them as stools or minibars).

Caution

Some temperature-sensitive products are seriously damaged by freezing:

  • Use only ice packs filled with water! Ice packs pre-filled with coloured refrigerant gel are not suitable since they have a freezing point below 0 ºC.
  • Wait for the frozen ice packs to rise to 0 ºC before placing them in the cold-box (keep them at room temperature for at least 30 minutes until water is visible inside).
  • Place cardboard between the temperature-sensitive products and the ice packs to prevent them touching.

In order to be able to rotate ice packs, it is useful to order an extra set per cold-box.
