PHASE INDICATOR non-contact (Kyoritsu K8035)
Form
Non-contact phase indicator for detecting phase rotation and open-phase presence using electrostatic induction
shape: handheld rectangular device with front LEDs and side clamp sensors
material: insulated ABS housing with double-insulated test leads
standards: IEC 61010-1 CAT Ⅳ 600 V / CAT Ⅲ 1000 V
electrical characteristics:
measuring voltage 70–1000 V AC phase-to-phase
measuring frequency 45–66 Hz
detection by electrostatic induction
clamp capacity Ø2.4...30 mm insulated cables
power supply: LR6 (AA) 1.5 V × 4
dimensions: 112 × 61 × 36 mm
weight: 380 g
Includes:
- carrying case model
- LR6 (AA) × 4
- instruction manual
Per piece.
Fit
installation method: non-contact measurement using clamp placement around insulated cables Ø2.4–30 mm
user interface compatibility: LED visual indication and buzzer tones for rotation direction and warnings
Function
- detect phase rotation (clockwise or counter-clockwise) and presence of open phase
phase rotation indication: clockwise with green rotating LEDs, green “CW” symbol and intermittent buzzer, counter-clockwise with red rotating LEDs, red “CCW” symbol and continuous buzzer
