BATTERY MONITOR (Victron SmartShunt) 500A, 50mV, IP65

Form

Battery monitor module with integrated shunt for high current DC systems.

  • voltage range: 6,5-70 VDC
  • current rating: 500 A / 50 mV shunt drop
  • shape: rectangular housing with mounting feet, bolts for shunt connections
  • material: rugged plastic enclosure rated IP65, exposed bolts M10
  • standards: CE compliance, IP65 water and dust resistance, bluetooth + VE.direct communication protocols
  • operating temperature: -40,+50 °C
  • dimensions (h × w × d): 46 × 120 × 54 mm
  • weight: 0.5 kg

Includes :

  • 1 x smartshunt IP65 unit
  • 2 x 1,5 m power cables with fuse
  • 1 x VE.direct port cable
  • 1 x user manual

Per piece.

Fit

Interconnections:

  • shunt connections: battery minus (M10 bolts), load minus (M10 bolts)

  • positive battery connection: with fused red lead M10 ring terminal

  • auxiliary input: voltage of second battery or midpoint or temperature sensor (optional)

  • communication: bluetooth built-in, ve.direct port

Electrical interface:

  • supply voltage range: 6,5-70 V DC

  • standby current draw: < 1 mA

  • auxiliary input voltage: 6.5-70 V DC

Connectivity: Wireless via bluetooth with victronconnect app, wired via ve.direct cable for GX / remote access.

Compatibility:Works with lead acid, gel, AGM, Li-ion battery.

Function

Used to monitor battery bank status, current flow, voltage, state of charge, amp-hours consumed and remaining time.

Usage: Installed inline on the negative line between battery and loads/chargers; display and controls via app or linked devices.

Specific use (MSF context): Provides precise battery status in emergency power systems, off-grid clinics, vehicles, allows avoiding unexpected battery depletion, helps plan recharging and load management.

Storing conditions: Store in dry, cool place, avoid prolonged exposure to salt water or corrosive atmosphere, ensure bolts clean and connections tight.

Use precautions: Ensure correct orientation of load minus vs battery minus, torque on bolts per spec, ensure fuses installed, avoid placing VE.Direct port where moisture can enter; firmware updates via app.
