CHARGER-INVERTER hybrid (Sungrow SH25T) 25kVA, 50kWp

Form

Three-phase hybrid inverter rated 25.0 kW AC with integrated whole-home backup and high-voltage Li-ion battery interface.


Electrical characteristics:

  • maximum DC input: 1000 V
  • MPPT range: 150–950 V
  • rated PV input: 600 V
  • maximum DC input current: 80 A (32/32/16 A)
  • rated AC output power: 25,000 W
  • maximum AC output current: 37.9 A
  • battery type: Li-ion with 100–700 V battery voltage range
  • maximum charge/discharge current: 50 A

Material: Transformerless design, wall-mount enclosure.

Safety ratings: IP65 enclosure, integrated surge protection DC Type II / AC Type II, AFCI support, grid/battery reverse-polarity, AC short-circuit and leakage-current protections.

Operating temperature: −25 °C to +60 °C

Thermosensitivity: allowable relative humidity 0–100 % non-condensing, maximum operating altitude 2000 m.

Dimensions: 620 × 480 × 245 mm
Weight: 40 kg

Includes:

  • 1 × Sungrow SH25T inverter unit
  • 1 × WiNet dongle
  • 1 × energy meter
  • 3 × current transformers

Per piece.

Fit

Connections: PV inputs via MC4-compatible connectors (PV cable up to 6 mm²), battery plug-and-play connector (up to 10 mm²),AC plug-and-play connector (up to 16 mm²)

Interfaces and interconnections: RS485, Ethernet, WLAN, CAN, DI × 4, DO × 2, DRM0, LED local display, compatible with Sungrow iSolarCloud monitoring via communication module

Compatibility: Three-phase 3/N/PE grids at 220/380 V, 230/400 V or 240/415 V, whole-home backup with built-in 63 A bypass, seamless switchover < 10 ms, supports 100 % unbalanced output in backup and on-grid.

Function

Manage PVgenerated energy , battery charging/discharging and grid feed-in with hybrid operation, while providing whole-home backup power.

Usage: Connect PV strings to the three MPPT inputs, wire the three-phase AC grid and backup circuits, connect a compatible high-voltage Li-ion battery, then commission and monitor via iSolarCloud through RS485, Ethernet or WLAN.

Limitations: Maximum PV input voltage 1000 V, backup output current up to 3 × 63 A, maximum operating altitude 2000 m, operating temperature −25 °C to +60 °C, off-grid THD(V) ≤ 2 % at linear load, country grid code settings must match local regulations.

Durability: IP65 enclosure with C5 corrosion category on product line, fan cooling for SH25T, designed for outdoor or indoor installation.

Storing conditions: Keep in original packaging in a dry, non-condensing environment, if storage temperatures are not specified, keep within the operating range −25 °C to +60 °C.
