SPIRAL HOSE, 3", NP5, 8m + 2 half-couplings + lock
STD
CWATHOSS3085H
Valid Article
Account code:
61110
HS Code:
391731
Last Updated on:
11/12/2024, 20:07:33
Former
Code(s):
CWATHOSS3SC
OC subscriptions: included in supply or field order tools (e.g. UniField)
|
|
SC subscriptions: included in supply or field tools
|
|
OC validations: approved for procurement and use by an OC for international or local orders specifying context and activity in Medical Standard Lists (MSL)
|
|
HOSE spiral, 3", NP5, 8m + set couplings
Form
Spiral hose, length 8 metre and 3" diameter, with two Guillemin-type symmetric half-couplings mounted on its ends. Should be food grade quality, but preferably drinking water quality. Maximum nominal pressure NP5 resisting up to 5 bar. Unit of measurement: 1 piece.
Fit
Fits to other 3” Guillemin-type symmetric half-couplings.
To ensure a leakage-free assembly the gasket/seal must be present and free of debris.
Function
Used for drinking water suction and delivery.
