MODULE, MAINTENANCE, 10 services, for HZJ7#
STD
KTRAMMAI72-
Valid Article
Account code:
61210
HS Code:
870899
Last Updated on:
11/12/2024, 22:02:49
Former
Code(s):
-X
OC subscriptions: included in supply or field order tools (e.g. UniField)
|
|
SC subscriptions: included in supply or field tools
|
|
OC validations: approved for procurement and use by an OC for international or local orders specifying context and activity in Medical Standard Lists (MSL)
|
|
MODULE, MAINTENANCE, 10 services, for HZJ7#
Definition
Spare parts necessary for the regular maintenance of a Toyota HZJ 76, 78 or 79.
Indications
Set of spare parts and consumables for carrying out 10 services on a Toyota HZJ 76, 78 or 79 series 2, which should cover 1.5 to 2 years. The module includes only genuine parts.
Supplied in a metal trunk.
Remark: The composition of the kit varies per ESC.
Instructions for use
It is recommended to order one module with each new vehicle, except for missions which have a workshop and a spare parts stock at their disposal.
Some restricted information has been hidden. Sign in
to see this information
![[PPACPADLFB2OU] PADLOCK 4 letters, brass, 20mm, open shackle](/web/image/product.template/546541/image_256/%5BPPACPADLFB2OU%5D%20PADLOCK%204%20letters%2C%20brass%2C%2020mm%2C%20open%20shackle?unique=47a06d3)
![[PPACPADLKB4] PADLOCK, brass, 40mm + key](/web/image/product.template/546544/image_256/%5BPPACPADLKB4%5D%20PADLOCK%2C%20brass%2C%2040mm%20%2B%20key?unique=ad0959a)
![[PPACTRUNM22] TRUNK, metal, 100cm, 220l](/web/image/product.template/547622/image_256/%5BPPACTRUNM22%5D%20TRUNK%2C%20metal%2C%20100cm%2C%20220l?unique=0eaf6ec)
![[TTYRINNE1623B] INNER TUBE, 7.5x16" or 235x16", bended valve 70mm](/web/image/product.template/553495/image_256/%5BTTYRINNE1623B%5D%20INNER%20TUBE%2C%207.5x16%22%20or%20235x16%22%2C%20bended%20valve%2070mm?unique=358ae04)
![[TVEASCRER2-] RADIATOR PROTECTION net, for HZJ7# Mk2](/web/image/product.template/552949/image_256/%5BTVEASCRER2-%5D%20RADIATOR%20PROTECTION%20net%2C%20for%20HZJ7%23%20Mk2?unique=87f78f8)
![[TVEASCRERVT] (radiator protection net) TIGHTENER for fixing](/web/image/product.template/552928/image_256/%5BTVEASCRERVT%5D%20%28radiator%20protection%20net%29%20TIGHTENER%20for%20fixing?unique=2e99ee3)
![[TVECBULB1S3] BULB BOX, 12V, H4 cap, 3 pins socket, set](/web/image/product.template/552901/image_256/%5BTVECBULB1S3%5D%20BULB%20BOX%2C%2012V%2C%20H4%20cap%2C%203%20pins%20socket%2C%20set?unique=1ab3115)
![[TVECCOOLC5R] COOLANT LIQUID cooling system, 5l, ready to use, tin](/web/image/product.template/552908/image_256/%5BTVECCOOLC5R%5D%20COOLANT%20LIQUID%20cooling%20system%2C%205l%2C%20ready%20to%20use%2C%20tin?unique=72b7bb5)
![[TVECFILTHW-] (manual fuel pump) FILTER water retention (Hydrosorb)](/web/image/product.template/549694/image_256/%5BTVECFILTHW-%5D%20%28manual%20fuel%20pump%29%20FILTER%20water%20retention%20%28Hydrosorb%29?unique=67f41ea)
![[TVECFLUIB4H] BRAKE FLUID, 0.5l, DOT4, can](/web/image/product.template/553897/image_256/%5BTVECFLUIB4H%5D%20BRAKE%20FLUID%2C%200.5l%2C%20DOT4%2C%20can?unique=f4a095b)
![[TVECFLUITD1] HYDRAULIC TRANSMISSION FLUID (Dexron II or III) 1l, can](/web/image/product.template/553902/image_256/%5BTVECFLUITD1%5D%20HYDRAULIC%20TRANSMISSION%20FLUID%20%28Dexron%20II%20or%20III%29%201l%2C%20can?unique=1ab3115)
![[TVECGREA04L] GREASE (NLGI-2) lithium, 0.4kg, multipurpose, cartridge](/web/image/product.template/553859/image_256/%5BTVECGREA04L%5D%20GREASE%20%28NLGI-2%29%20lithium%2C%200.4kg%2C%20multipurpose%2C%20cartridge?unique=87f78f8)
![[TVECOILE5405] ENGINE OIL 15W40 API SJ/CF, 5l, petrol / diesel, can](/web/image/product.template/553619/image_256/%5BTVECOILE5405%5D%20ENGINE%20OIL%2015W40%20API%20SJ-CF%2C%205l%2C%20petrol%20-%20diesel%2C%20can?unique=2e99ee3)
![[TVECPASTWT-] WATER DETECTING PASTE, for fuel, tube](/web/image/product.template/553543/image_256/%5BTVECPASTWT-%5D%20WATER%20DETECTING%20PASTE%2C%20for%20fuel%2C%20tube?unique=86f2876)
![[TVECSPAR7AR] (HZJ78/79) BUSH SET, for RR shock absorber, set](/web/image/product.template/554081/image_256/%5BTVECSPAR7AR%5D%20%28HZJ78-79%29%20BUSH%20SET%2C%20for%20RR%20shock%20absorber%2C%20set?unique=0cc4c4c)
![[TVECSPAR7PB] (HZJ78/79) BUSH, for inner RR spring pin, set](/web/image/product.template/546007/image_256/%5BTVECSPAR7PB%5D%20%28HZJ78-79%29%20BUSH%2C%20for%20inner%20RR%20spring%20pin%2C%20set?unique=0cc4c4c)
![[TVECSPAR7RB] (HZJ78/79) BUSH, for lower RR spring shackle](/web/image/product.template/546012/image_256/%5BTVECSPAR7RB%5D%20%28HZJ78-79%29%20BUSH%2C%20for%20lower%20RR%20spring%20shackle?unique=0cc4c4c)
![[YTOY04234-68010] PRE-FILTER ELEMENT fuel + gasket](/web/image/product.template/545967/image_256/%5BYTOY04234-68010%5D%20PRE-FILTER%20ELEMENT%20fuel%20%2B%20gasket?unique=1ab3115)
![[YTOY04465-60340] PAD KIT disc brake, FR, HZJ78/79](/web/image/product.template/545932/image_256/%5BYTOY04465-60340%5D%20PAD%20KIT%20disc%20brake%2C%20FR%2C%20HZJ78-79?unique=4c376d8)
![[YTOY04495-60070] SHOE KIT RR brake, HZJ78/79](/web/image/product.template/545683/image_256/%5BYTOY04495-60070%5D%20SHOE%20KIT%20RR%20brake%2C%20HZJ78-79?unique=f79dfa2)
![[YTOY17801-61030] AIR FILTER ELEMENT, dry, washable, HZJ78/79](/web/image/product.template/546402/image_256/%5BYTOY17801-61030%5D%20AIR%20FILTER%20ELEMENT%2C%20dry%2C%20washable%2C%20HZJ78-79?unique=4c376d8)
![[YTOY23390-51070] FUEL FILTER element, HZJ7# Mk2](/web/image/product.template/550124/image_256/%5BYTOY23390-51070%5D%20FUEL%20FILTER%20element%2C%20HZJ7%23%20Mk2?unique=3ffb3a8)
![[YTOY31478-30010] CAP bleeder plug brake / clutch, HZJ78/79](/web/image/product.template/550069/image_256/%5BYTOY31478-30010%5D%20CAP%20bleeder%20plug%20brake%20-%20clutch%2C%20HZJ78-79?unique=f79dfa2)
![[YTOY47491-20011] PLUG, OVAL brake back plate, RR, HZJ78/79](/web/image/product.template/550517/image_256/%5BYTOY47491-20011%5D%20PLUG%2C%20OVAL%20brake%20back%20plate%2C%20RR%2C%20HZJ78-79?unique=4c376d8)
![[YTOY47492-28010] PLUG, ROUND brake back plate, RR, HZJ78/79](/web/image/product.template/550529/image_256/%5BYTOY47492-28010%5D%20PLUG%2C%20ROUND%20brake%20back%20plate%2C%20RR%2C%20HZJ78-79?unique=e1d45d9)
![[YTOY48511-69676] SHOCK ABSORBER, FR, left & right, HZJ78/79 Mk2](/web/image/product.template/568289/image_256/%5BYTOY48511-69676%5D%20SHOCK%20ABSORBER%2C%20FR%2C%20left%20%26%20right%2C%20HZJ78-79%20Mk2?unique=069cd04)
![[YTOY48531-69855] SHOCK ABSORBER, RR, left & right, HZJ78/79 Mk2](/web/image/product.template/550446/image_256/%5BYTOY48531-69855%5D%20SHOCK%20ABSORBER%2C%20RR%2C%20left%20%26%20right%2C%20HZJ78-79%20Mk2?unique=c126707)
![[YTOY90341-12012] DRAIN PLUG engine sump, HZJ78/79 KUN/LAN LN202](/web/image/product.template/552253/image_256/%5BYTOY90341-12012%5D%20DRAIN%20PLUG%20engine%20sump%2C%20HZJ78-79%20KUN-LAN%20LN202?unique=63d5afe)
![[YTOY90341-18006] FILLER PLUG transmission, HZJ78/79 KUN/LAN LN202](/web/image/product.template/552249/image_256/%5BYTOY90341-18006%5D%20FILLER%20PLUG%20transmission%2C%20HZJ78-79%20KUN-LAN%20LN202?unique=9d8cad2)
![[YTOY90416-07001] (HZJ78/79) GREASE NIPPLE straight](/web/image/product.template/573310/image_256/%5BYTOY90416-07001%5D%20%28HZJ78-79%29%20GREASE%20NIPPLE%20straight?unique=81b450c)
![[YTOY90430-12031] GASKET oil sump drain plug](/web/image/product.template/552203/image_256/%5BYTOY90430-12031%5D%20GASKET%20oil%20sump%20drain%20plug?unique=81b450c)
![[YTOY90430-18008] GASKET drain & filler plugs gear cases, HZJ7#](/web/image/product.template/552233/image_256/%5BYTOY90430-18008%5D%20GASKET%20drain%20%26%20filler%20plugs%20gear%20cases%2C%20HZJ7%23?unique=81b450c)
![[YTOY90915-30002-8T] OIL FILTER cartridge, HZJ7#](/web/image/product.template/552453/image_256/%5BYTOY90915-30002-8T%5D%20OIL%20FILTER%20cartridge%2C%20HZJ7%23?unique=9d8cad2)
![[YTOY90942-01101] WHEEL NUT, HZJ7#](/web/image/product.template/553397/image_256/%5BYTOY90942-01101%5D%20WHEEL%20NUT%2C%20HZJ7%23?unique=f739a5f)
![[YTOY90942-02083] STUD wheel, FR&RR, HZJ7#](/web/image/product.template/553071/image_256/%5BYTOY90942-02083%5D%20STUD%20wheel%2C%20FR%26RR%2C%20HZJ7%23?unique=6e983cd)
![[TVECOILG8902] TRANSMISSION OIL, 2l, EP 80W90 GL5, can](/web/image/product.template/553531/image_256/%5BTVECOILG8902%5D%20TRANSMISSION%20OIL%2C%202l%2C%20EP%2080W90%20GL5%2C%20can?unique=0cc4c4c)
![[TTOYLC78D11L] LANDCRUISER 4x4 (HZJ78) 11 seats, diesel LHD hard-top](/web/image/product.template/552566/image_256/%5BTTOYLC78D11L%5D%20LANDCRUISER%204x4%20%28HZJ78%29%2011%20seats%2C%20diesel%20LHD%20hard-top?unique=53ec84a)
![[TTOYLC79D03L] LANDCRUISER 4x4 (HZJ79) 3 seats, diesel LHD pick-up](/web/image/product.template/553384/image_256/%5BTTOYLC79D03L%5D%20LANDCRUISER%204x4%20%28HZJ79%29%203%20seats%2C%20diesel%20LHD%20pick-up?unique=53ec84a)
