CIRCUIT BREAKER MCB C-curve, 63A Icu15kA, 4P mod

https://unicat.msf.org/cat/product/43824
NST PELEMCB04C63X

Valid Article

Former Code(s): PELEZFR0288 PELEMMCB4C63X PELEMMCB4C635
OC subscriptions: included in supply or field order tools (e.g. UniField)
SC subscriptions: included in supply or field tools
OC validations: approved for procurement and use by an OC for international or local orders specifying context and activity in Medical Standard Lists (MSL)

This combination does not exist.

Add article to list


Create Cancel

Add Kit To Wishlist


Create Cancel

CIRCUIT BREAKER MCB C-curve, 63A, Icu 15kA, 4P mod

Form

  • Circuit breaker 4 pole, 63 Amps, C Curve 15 kA Icu conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz. Thermal-magnetic.
  • Single terminal, top or bottom rigid wire(s) 1-35 mm² max
  • Single terminal, top or bottom flexible wire(s) 1-25 mm² max
  • Operational temperature: -35 +70 °C
  • Height: 88mm
  • Width: 70mm
  • Depth: 69mm
  • Weight 0.5kg

Open article.

Fit

Compatible with main circuit and distribution boards of similar make and technical specifications.

Function

MCBs or Miniature Circuit Breakers are electromechanical devices which protect an electrical circuit from an over current.

A MCB functions by interrupting the continuity of electrical flow through the circuit once a fault is detected.
