KIT VHF, TRANSCEIVER, base (Icom IC-F5061DP v1)
Valid Article
OC subscriptions: included in supply or field order tools (e.g. UniField)
|
|
SC subscriptions: included in supply or field tools
|
|
OC validations: approved for procurement and use by an OC for international or local orders specifying context and activity in Medical Standard Lists (MSL)
|
|
KIT VHF, TRANSCEIVER, base (ICF5061DP)
Definition
VHF radio kit, wide band, for base station, intended for short distance communications.
Indications
Includes 1 transceiver and 1 base antenna. For the specifications, see the Logistic catalogue.
VHF handset
CLOSED ARTICLE (Icom ICF3262DT)
VHF transceiver
CLOSED ARTICLE (Icom ICF5061DP)
Remark
MSF-OCA supplies a transceiver of another brand, but with similar specifications (Kenwood TM 271).
VHF antenna
CLOSED ARTICLE (Kathrein K711530)
Instructions for use
Always enquire about local authorizations to be obtained.
Wide band, duplex mode, and front panel programming allow the communication with other operators (except if they use UHF equipment), and the use of a repeater.
Radios are pre-programmed on standard frequencies, for immediate use.
NEVER transmit without antenna.
The antenna of the handset is fragile and is not a carrying handle. The handset range depends on environmental conditions, and is 8 km maximum.
ALWAYS USE THE PROTECTIVE SOFT CASE SUPPLIED WITH THE HANDSET.
The antenna of the base station should be erected as high as possible. The base station range depends on the antenna height, and is 30 km maximum. The base station should ideally be placed in the middle of the site, with a permanent operator in charge of relaying the messages, in order to extend the communication network.
For special situations (longer distance, repeater...), please contact your technical department.
