BATTERY CHARGER (Victron Bluesmart) 12V/15A in 230V, IP65
Valid Article
BATTERY CHARGER (Victron Bluesmart) 12V/15A in 230V, IP65
Form
A portable and professional battery charger for 12 V lead-acid and LiFePO₄ batteries.
- bluetooth
- adaptative 7-stage charging algorithm
- material: rugged plastic housing with sealed electronics for dust, water, and chemical resistance
- dimensions: 60 × 105 × 190 mm
- weight: 0.9 kg
- IP65: splashproof and dustproof
- safety standards: emissions and immunity compliant with EN 55014-1, EN 61000-6-3, EN 55014-2, EN 61000-6-1, EN 61000-6-2, EN 61000-3-2, EN 61000-3-3
- thermo-sensitivity: operates from –30 °C to +50 °C (full rated output up to 30 °C) with automatic temperature compensation for lead-acid charging.
Includes:
- a pair of 1.5 m black and red output cable with M8 eyelet
- a pair of 1.5 m black and red output cable with crocodille clam
- a 1.5 m cable power cord for 230 VAC-connection with a plug type that matches the regional standard
Per piece.
Fit
Electrical interface:
- input: 100–250 VAC, 45–65 Hz
- output: 12 V DC, 15 A maximum nominal charging current
The charger is powered by a 230 V AC wall socket. It comes with a 1.5 m power cable fitted with a plug that complies with regional standards.
Connectivity: Built-in Bluetooth Smart for wireless setup, monitoring, and configuration via the VictronConnect mobile app (iOS/Android).
Wireless range up to 10 m.
Compatible with batteries and Victron accessories.
Function
Charges, maintains, and recovers batteries.
Usage:Connect to battery using supplied clamps or eyelets, select mode via bluetooth or automatic detection and leave to operate unattended.
Specific use: Ideal for field missions where robust, adaptable charging is required for vehicles, boats, generators, and medical equipment batteries, with the added benefit of remote status monitoring.
Limitations:
- not suitabale for unsupported battery chemistries
- full current output derated above 30 °C.
Use precautions:
- place the charger as far from the battery as the cable length allows
- do not position the charger directly above the battery to avoid gas corrosion
- ensure good ventilation during operation, do not operate in a confined space
- prevent acid from dripping on the charger
- never place a battery on top of the charger
