BATTERY CHARGER (Victron Bluesmart) 12V/15A in 230V, IP65

Form

A portable and professional battery charger for 12 V lead-acid and LiFePO₄ batteries.

  • bluetooth
  • adaptative 7-stage charging algorithm
  • material: rugged plastic housing with sealed electronics for dust, water, and chemical resistance
  • dimensions: 60 × 105 × 190 mm
  • weight: 0.9 kg
  • IP65: splashproof and dustproof
  • safety standards: emissions and immunity compliant with EN 55014-1, EN 61000-6-3, EN 55014-2, EN 61000-6-1, EN 61000-6-2, EN 61000-3-2, EN 61000-3-3
  • thermo-sensitivity: operates from –30 °C to +50 °C (full rated output up to 30 °C) with automatic temperature compensation for lead-acid charging.

Includes:

  • a pair of 1.5 m black and red output cable with M8 eyelet
  • a pair of 1.5 m black and red output cable with crocodille clam
  • a 1.5 m cable power cord for 230 VAC-connection with a plug type that matches the regional standard

Per piece.


Fit

Electrical interface:

  • input: 100–250 VAC, 45–65 Hz
  • output: 12 V DC, 15 A maximum nominal charging current

The charger is powered by a 230 V AC wall socket. It comes with a 1.5 m power cable fitted with a plug that complies with regional standards.

Connectivity: Built-in Bluetooth Smart for wireless setup, monitoring, and configuration via the VictronConnect mobile app (iOS/Android).

Wireless range up to 10 m.

Compatible with batteries and Victron accessories.

Function

Charges, maintains, and recovers batteries.

Usage:Connect to battery using supplied clamps or eyelets, select mode via bluetooth or automatic detection and leave to operate unattended.

Specific use: Ideal for field missions where robust, adaptable charging is required for vehicles, boats, generators, and medical equipment batteries, with the added benefit of remote status monitoring.

Limitations:

  • not suitabale for unsupported battery chemistries
  • full current output derated above 30 °C.

U​se precautions:

  • place the charger as far from the battery as the cable length allows
  • do not position the charger directly above the battery to avoid gas corrosion
  • ensure good ventilation during operation, do not operate in a confined space
  • prevent acid from dripping on the charger
  • never place a battery on top of the charger
