MONITOR, multiparameter (Procare B40)+ accessories, 230V

https://unicat.msf.org/cat/product/53966
NST EEMDMONE3--

Outdated Article

Former Code(s): EHOEMONE3-- EANEMISC172 EANEZFR0172 EANEMISC105 EANEZNL0105
CE marking: declaration that the product meets EU standards for health, safety, and environmental protection. The CE marking indicates that the product may be sold freely in any part of the European Economic Area, regardless of its country of origin.
IIb
In Europe, medical material that fulfills the definition of a medical device according to the MDR (Medical Device Regulation) is classified into 4 classes
P
The order of this product needs to be justified and is only acceptable under certain conditions.
UN3481
Hazardous materials and products (identified by their 4-digit transport UN-number) must be transported under certain conditions as specified in the MSDS sheet (Material Safety Data Sheet).
OC subscriptions: included in supply or field order tools (e.g. UniField)
SC subscriptions: included in supply or field tools
OC validations: approved for procurement and use by an OC for international or local orders specifying context and activity in Medical Standard Lists (MSL)

This combination does not exist.

See Related

Add article to list


Create Cancel

Add Kit To Wishlist


Create Cancel

Documents

MONITOR multiparameter (PROCARE B40 V2)

The monitor Procare B40 V2 is no longer produced by GE Healthcare. The EMACC and biomedical groups are currently looking for a replacement.

In the meanwhile the B125 is the replacement monitor (see “replaced by” at bottom of the page).

Definition

Portable, vital signs monitor, used to provide continuous measurement of electrocardiogram, pulse oximetry and capnography, and discontinuous measurement of non-invasive blood pressure (NIBP).

Specifications

Some restricted information has been hidden. Sign in to see this information

Quality standards

EN 60601-2-49, 2002, Medical electrical equipment - Part 2-49 : Particular requirements for the safety of multifunction patient monitoring equipment

Components

  • 1 monitor with colour screen = 26.4 cm display
  • 1 power cable
  • 2 Lithium-Ion batteries
  • 1 instructions manual

Technical specifications

  • Display:
    • ECG graph (3 leads) + pulse rate
    • expired CO2 waveform in mmHg
    • values for SpO2 (%) and plethysmographic waveform
    • values for non-invasive blood pressure (systolic, diastolic, and mean pressures)
    • trend data
  • Adjustable alarms: peripheral pulse rate, saturation, blood pressure, CO2, pulse and respiratory rates
  • Power supply: 200-240 V/50 Hz (comes also in 110V/60 Hz) and Lithium-Ion battery (4 h ; 39 Wh)

Transport Dangerous Goods

  • UN3481 Lithium ion batteries contained in equipment
  • Class: 9
  • Packing Instructions: 967 Section II
  • The label must include the UN code of the battery + an emergency number to contact in case of an incident
  • Limit per package:
    • Pax A/C (Passengers & Cargo Aircraft) = 5 kg
    • CAO (Cargo Aircraft Only) = 5 kg

Supplied with the Article

  • ECG
    • 1 multi-link ECG cable
    • 2 clip 3-Ld ECG lead wires
    • 3 boxes of 300 electrodes
  • CAPNO
    • 1 CO2 sensor, "sidestream" E-miniC
    • 1 CO2 airway adapter adult/paediatric
  • SpO2
    • 1 SpO2 interface cable
    • 2 reusable adult finger sensors
    • 1 reusable neonatal sensor
    • 2 x 100 adhesive tapes for neonatal sensors
  • NIBP
    • 2 NIBP dual hoses
    • 9 BP cuffs (2 paediatric, 2 small adult, 3 adult, 2 large adult)
  • Temperature
    • 1 temperature cable 0.5 m (EEMDMONA103)
    • 1 skin temperature probe Ø10mm, reusable (EEMDMONA125)
    • 1 temperature probe general use, Ø3mm, reusable (EEMDMONA122)

Instructions for use

Device intended for the monitoring of patients in peri-operative activity or intensive care.

This capnography system must always be used with a hydrophobic antibacterial filter.

Operating conditions

  • 0-40ºC, CO2 sensor 10-40ºC
  • Relative humidity 5-95% at 4ºC

Precautions for Use

Secure the electrical protection of the apparatus with a double conversion UPS (see related articles below).

MSF requirements

The pulse oximeter and the capnograph are part of the basic anaesthetic equipment of any operating theatre.

Some restricted information has been hidden. Sign in to see this information
Some restricted information has been hidden. Sign in to see this information
