(blds.syst.) TUBE, VACUUM, plastic, K2EDTA, 4ml, purple

STD STSSBSVT5E-

Valid Article

Former Code(s): ELAEBSVT5E- ELABBSVT5E-
The product is supplied (and stored) sterile, it must remain sterile until its use. Sterile = state of being free from all living microorganisms.
Single use
A single-use device, also referred to as a disposable device, is intended for use on one patient during a single procedure. It is not intended to be reprocessed (i.e., cleaned and disinfected or sterilized).
CE marking: declaration that the product meets EU standards for health, safety, and environmental protection. The CE marking indicates that the product may be sold freely in any part of the European Economic Area, regardless of its country of origin.
16
Shelf life = length of time a product can remain active and effective. Short shelf life = shelf life = < 24 months
W050101010201 - Blood collection, tubes with additives or serum separator
European Medical Device Nomenclature (EMDN) is the nomenclature of use by manufacturers when registering their medical devices in the EUDAMED database. EMDN is characterised by its alphanumeric structure that is established in a seven-level hierarchical tree.
Thermosensitive codes are defined for storage and transportation temperature requirements of the products.
The product is part of at least one Kit. A kit is a collection of products (medical and/or logistic) that are needed for a certain intervention in emergency. The choice and quantity of the articles reflects the MSF protocols for this specific situation. The use of Kits allows to start an intervention without a detailed evaluation.
OC subscriptions: included in supply or field order tools (e.g. UniField)
SC subscriptions: included in supply or field tools
OC validations: approved for procurement and use by an OC for international or local orders specifying context and activity in Medical Standard Lists (MSL)

(blood sampling) VACUUM TUBE

Definition

Vacuum sterile tube, with or without additive, intended to contain a blood specimen.

Specifications

Some restricted information has been hidden. Sign in to see this information

Quality Standards Comment

EN ISO 6710 : 2017: Single-use containers for human venous blood specimen collection (ISO 6710:2017)

Material

  • Tube: polyethylene tetraphtalate (PET) and polypropylene (PP) except STSSBSVTG5S: glass
  • Cap: polymer (low density Polyethylene resin)
  • Closure: bromobutyl elastomer

Technical specifications

  • Vacuum tube, sterile, for single use
  • Dimensions: 75 mm x 13 mm Ø
  • Perforable plug
  • Paper label
  • All 3 brands compatible with the Vacutainer blood sampling system

STSSBSVT2E-

  • EDTA K2 tube, volume 5 ml, vacuum 2 ml
  • EDTA K2 sprayed on the internal wall
  • plug colour: purple

STSSBSVT5E-

  • EDTA K2 tube, volume 5 ml, vacuum 4 ml
  • EDTA K2 sprayed on the internal wall
  • plug colour: purple

STSSBSVT2HL

  • heparinized tube, volume 5 ml, vacuum 2 ml (except Lind-Vac: 3ml)
  • contains : lithium heparin
  • plug colour: green

STSSBSVT5HL

  • heparinized tube, volume 5 ml, vacuum 4 ml
  • contains : lithium heparin
  • plug colour: green

STSSBSVT2S-

  • siliconized serum tube, volume 5 ml, vacuum 2 ml
  • plain tube, no additive (except Vacutainer, with clot activator (silicium))
  • plug colour: red (brick)

STSSBSVT5S-

  • siliconized serum tube, volume 5 ml, vacuum 4 ml
  • plain tube, no additive (except Vacutainer, with clot activator (silicium))
  • plug colour: red (brick)

STSSBSVTG5S

  • glass
  • serum tube, volume 5 ml
  • plain tube, uncoated, no additives
  • plug colour: red (brick)

STSSBSVT2C-

  • citrate tube, volume 5 ml, vacuum 2.7 ml (except Vacuette: 3 ml)
  • contains: buffered trisodium citrate solution
  • plug colour: translucent light blue

Packaging & Labelling

Instructions for use

EDTA tubes are aimed for haematological tests and blood transfusion tests.

Heparinized tubes are to be used for biochemistry tests (i-STAT) in sleeping sickness/trypanosomiasis projects for the mini Anion Exchange Centrifugation Technique (mAECT).

Serum tubes are aimed for screening tests and biochemistry tests.

Glass serum tubes are aimed for early diagnosis and monitoring of coagulation abnormalities based on a clotting test (e.g. snake bites)

Citrate tubes are aimed for coagulation studies.

2 ml tubes are to be used for newborns and children.

Please consult the “Updated laboratory procedures, 2022” available online via the Laboratory working Group sharepoint page: Laboratory Procedures and Resources.

https://msfintl.sharepoint.com/sites/msfintlcommunities/LabWG/SitePages/Laboratory-Manual-page.aspx

For offline access, contact your laboratory advisor.

Please consult the “Manual of nursing Care Procedures, MSF, 2020” available online via the Nursing care working Group sharepoint page.

Some restricted information has been hidden. Sign in to see this information

Storage

  • Store between 4 and 25°C, Protect from sunlight ‐ Protect from humidity
  • Do not freeze
  • Shelf life: depending on the manufacturer
  • Not to be used beyond expiry date

(Cf Introduction: Thermosensitive products)

Waste management

To be destroyed by incineration.

(Cf Public Health Engineering In Precarious situations, MSF, 2010, Chapter 6)

MSF requirements

Closed system ensuring a good security for the sample and the practitioner. Plastic tubes which can not break.

Some restricted information has been hidden. Sign in to see this information
